5-mar-24



CARGO VESSELS

6300 HP 160' CARGO / PROJECT SUPPORT VESSEL  (Ref#4115)

Built 2002, converted from crew/supply boat to handle cargo and project support operations and designed to operate in remote areas.  160’ x 29’ x 14’, 5.75’ light draft, 9.25’ max draft, 42’ air draft, 165.4LT light ship displacement, 490lt max displacement, 220 LT deck cargo capacity, 100’ x 25’ clear deck, main engines: (4) Cat 3512B, (4) ZF4600 gears 2.52:1 ratio, 5-blade 50 x 50 propellers, Cat 3306 blow thrusters with 125 hp key power, (2) 75 kw generators Cummins 6BT122-1800, 1000 gpm fire monitor, 25 knots speed light boat, 21 knots speed loaded, 35,380 gal fuel capacity, 50,800 gal potable water capacity, 828 gal ships potable, 160 gal lube oil capacity, 1455 gal dirty oil/bilge water capacity, 7010 gal rig water capacity, 988 gal sewage capacity, 539 gal grey water holding tank capacity, 3000 GPD water maker, sewage purification system, Solas electronic system, laundry, galley, 7 2-man staterooms, 3 heads, on main deck a new galley was added and crew boat seats removed.  Davit retrieval system, (2) 150 lb anchors, (2) 60-man life rafts, crane and 2 containers will be removed (not included).  ABS (valid until 2027), US flag, located USA, invested $2M  Price:  $1,150,000

2025 HP 156’ CARGO VESSEL  (Ref#4119)

Converted from supply vessel, manufactured 1978, 156’ x 36’ x 11.7’, approx. 35’ eye height, main engines: (2) Detroit 16V-149 diesel engines, keel cooled, (2) Twin Disc MG540 reduction gears 2.5:1 ratio, (2) 99kw Delco generators p/b Detroit 8V71 engines, (2) multi stage air compressor p/b 15hp electric motors, Dynapower bow thruster p/b 6V71 Detroit engine, approx. 35,000 gal fuel tank capacity, approx. 90,000 gal potable water capacity, approx. 1600 gal ballast water capacity, approx. 750 gal lube oil capacity, approx. 600 gal hyd oil capacity, approx. 4000 gal sewage/gray water tanks, loadline (freeboard) 1’9-1/2” summer, 2’ winter, internal mud tanks converted to general cargo holds with (2) 10’ x 10’ cargo hatches, Beier DP system in place but currently not being used, model bow, square stern, (1) 10 ton HBL winch and (1) capstan, (1) 10 ton SWL deck crane mounted on pedestal in center of aft cargo deck, galley, crew quarters: (7) 2-man bunkrooms, (1) 4-man bunkroom, (3) heads, currently operating in the Caribbean and will return to US in March 2024 for dry dock  Price:  $1,400,000

2000 HP SUPPLY BOAT  (Ref#4122a)

Built 1976, 165’ x 36’ x 12’, clear deck 110’ x 27’, 420T deck cargo capacity, 189 GT, main engines: (2) Cummins QSK38 Tier 2, 12 knots speed, (2) Cummins 6BT 75 kw generators, 250 hp bow thrusters, 125,000 gal transferrable fuel capacity, 80,000 gal potable water capacity, 2500 gal lube oil capacity, 2500 gal waste oil capacity, certified to carry 20 passengers, 16 berths, 6 staterooms, 3 heads/showers, 360 cu ft walk in cooler, communication and navigation equipment, two pad eye for emergency towing, 24” moon pool for current profiler, located Louisiana  Price:  $1,050,000

1000 HP CARGO BOAT (Ref#4059)

83’ x 16.4’ x 7.1’ depth, 6.2’ draft, main engine: T220-ET Yanmar (15459 hours), 12 knot service speed, 4000 gal capacity fuel tank, 1083 gal fresh water tank, 192 gal lube oil tank, (2) 60 kw gensets 6CHL-N w/Shinko, YC2-851 2-speed gear box, MG-64B electric/air compressor, hydraulic anchor/windless, 3 anchors, Hiab crane, solar panel for radio battery, on land, located Alabama  Price: $110,000
